Welcome to the Viper 5305V installation guide, designed for professionals and DIYers. This manual provides step-by-step instructions for installing and configuring your remote start and security system.
Follow the guide carefully to ensure proper installation, safety, and optimal performance of your Viper 5305V system. Refer to the troubleshooting section for common issues and solutions.
Pre-Installation Checklist
Ensure vehicle compatibility and gather all necessary tools and accessories. Disconnect the battery to prevent electrical shocks or damage during installation.
Review the manual for specific requirements and verify all components are included in the kit. Plan the wiring route and prepare the vehicle for a safe installation process.
Understanding the Components and Accessories
The Viper 5305V system includes a control module, wiring harness, remote controls, and sensors. The control module is the brain of the system, managing remote start and security features.
- Control Module: Houses the system’s electronics and connects to the vehicle’s wiring.
- Wiring Harness: Pre-wired cables for seamless installation, reducing the risk of errors.
- Remote Controls: Features a 4-button LCD remote for keyless entry, SmartStart, and remote start functionality.
- Sensors: Includes door, hood, and trunk sensors for comprehensive security monitoring.
Familiarize yourself with these components to ensure proper installation and functionality. Always refer to the manual for specific details and compatibility checks.
Vehicle Compatibility and Safety Precautions
Ensure your vehicle is compatible with the Viper 5305V system. It is designed for fuel-injected, automatic transmission vehicles only. Installation on manual transmission vehicles is unsafe and not recommended.
- Compatibility: Confirm your vehicle’s make and model are listed in the manual to avoid installation issues.
- Safety Precautions: Disconnect the battery before starting installation to prevent electrical shocks or damage.
- Warning: If the vehicle starts in gear during remote start, stop immediately and consult the manual for troubleshooting steps.
Adhering to these guidelines ensures a safe and successful installation. Always follow the manual’s instructions and manufacturer’s recommendations for optimal performance and security.
Installation Process
Follow the step-by-step guide to install the Viper 5305V system, including mounting the control module, connecting the wiring harness, and configuring remote start functionality.
Preparing the Vehicle for Installation
- Ensure the vehicle is parked on a level surface with the transmission in park (automatic) or first gear (manual).
- Engage the parking brake and turn off the ignition, lights, and all accessories to prevent accidental starts.
- Disconnect the negative battery terminal to avoid electrical shocks or damage during installation.
- Verify the vehicle is compatible with the Viper 5305V system, ensuring it is designed for fuel-injected, automatic transmission vehicles only.
- Locate the vehicle’s wiring harness and components, consulting the manual if unsure about compatibility or connections.
- Prepare the installation tools and accessories, such as wire cutters, connectors, and mounting hardware.
- Ensure the area is safe and well-ventilated to avoid hazards during the installation process.
By following these steps, you ensure a safe and efficient installation of the Viper 5305V system.
Mounting the Control Module
Mounting the control module securely is essential for proper system function. Locate a suitable spot, such as under the dashboard or in the glove compartment, ensuring it is dry and protected from moisture. Clean the area thoroughly before installation to avoid dust or debris interfering with connections. Use the provided mounting hardware, such as screws or adhesive, to secure the module firmly in place. Avoid areas with excessive heat or vibration. Once mounted, connect the wiring harness carefully, ensuring all connections are tight and properly routed. Test the module’s response to the remote to confirm functionality. Secure installation ensures reliable performance and long-term durability of the Viper 5305V system.
Connecting the Wiring Harness
Begin by identifying the wiring harness and matching the wires to the vehicle’s electrical system. Use the provided wiring diagram to ensure accurate connections. Start with the main power wire, connecting it to the battery’s positive terminal. The ground wire should be securely attached to a clean, bare metal surface. Next, connect the ignition wire to the ignition switch circuit. Carefully strip insulation from the ends of each wire and use solder or heat shrink connectors for a reliable connection.Route the wiring neatly, avoiding interference with moving parts like the steering column. Double-check all connections for tightness and proper routing. Finally, test the system to ensure all functions operate correctly, verifying remote start and alarm features. Always follow the manufacturer’s guidelines for wiring connections to ensure safety and functionality. Proper wiring is critical for the system’s performance and longevity. If unsure, consult a professional installer.
Configuring the Remote Start System
Configure the remote start system by programming the virtual tach and setting up keyless entry and SmartStart features for enhanced convenience and security.
Programming the Virtual Tach
Programming the Virtual Tach ensures proper communication between the remote start system and your vehicle’s engine. After completing the installation, remote start the engine to initiate the programming process. The system may require up to three crank cycles before the engine starts and runs smoothly. During this process, the tach learns your vehicle’s ignition timing. Once the engine starts and runs consistently, the Virtual Tach is successfully programmed. If the vehicle starts in gear, stop the remote start immediately and consult the manual for safety precautions. This feature is designed for fuel-injected, automatic transmission vehicles only. Proper programming ensures reliable remote start functionality.
Setting Up Keyless Entry and SmartStart Features
The Viper 5305V system includes advanced keyless entry and SmartStart features for enhanced convenience. To set up keyless entry, synchronize the remote control with your vehicle by pressing the lock button three times within five seconds. For SmartStart compatibility, download the SmartStart app and follow the in-app pairing instructions to connect your smartphone to the system. Ensure your vehicle is equipped with the necessary hardware for these features to function properly. Once configured, you can unlock doors, pop the trunk, and start your engine remotely using the LCD remote or your smartphone. Refer to the troubleshooting section if issues arise during setup.
Testing the System Post-Installation
After installation, test the remote start by ensuring the engine starts and runs properly. Verify the alarm system’s functionality by triggering and checking all sensors.
Remote Start Functionality Check
To verify the remote start functionality, ensure the vehicle is in a well-ventilated area. Press and hold the remote start button until the LED flashes. The engine should crank and start within three attempts. If the vehicle starts in gear, stop immediately and consult the manual for troubleshooting. Check that the engine runs smoothly and shuts off when the process is aborted. Repeat the test to confirm consistency. Ensure all safety features, like the tachometer learning, are correctly programmed to prevent malfunctions. If issues arise, refer to the troubleshooting section for guidance.
Alarm System Verification
After installation, verify the alarm system by testing its core functions. Arm and disarm the system using the remote to ensure proper operation. Activate the panic feature to check the siren and visual alerts. Test the impact sensor by gently tapping the vehicle to trigger the alarm. Ensure the perimeter protection responds correctly when doors, trunk, or hood are accessed. Verify that keyless entry functions work seamlessly with the system. Consult the manual for specific test procedures to ensure all features are operational. If any issues arise, refer to the troubleshooting section for resolution. Proper verification ensures your vehicle’s security and peace of mind.
Troubleshooting Common Issues
Identify and resolve common issues like remote start malfunctions or wiring problems. Consult the manual for detailed solutions and ensure all connections are secure and correct.
Addressing Remote Start Malfunctions
Remote start malfunctions can occur due to improper wiring or programming errors. Ensure the Virtual Tach is programmed correctly and the system is compatible with your vehicle. If the engine fails to start, check the remote battery and signal strength. Verify all wiring connections, especially the ignition and starter wires. Consult the troubleshooting section for detailed solutions. If issues persist, reset the system or reprogram the remote. Always refer to the manual for specific guidance and safety precautions to avoid further complications.
Resolving Wiring and Connection Problems
Wiring issues are common during installation. Verify all connections are secure and match the wiring diagram. Check for damaged or loose wires, especially in high-vibration areas. Ensure the correct wires are connected to the ignition, starter, and battery terminals. If the system malfunctionspost-installation, use a multimeter to test voltage and continuity. Consult the manual for specific wiring instructions and safety precautions. Grounding issues can cause system failures, so ensure the ground wire is properly connected to a clean metal surface. If problems persist, review the installation guide or seek professional assistance to avoid further complications.
After completing the installation, conduct a thorough safety inspection. Ensure all wires are securely connected and routed away from moving components. Test the remote start and alarm functions to confirm proper operation. Verify that the vehicle does not start in gear during remote start; Check the ground wire connection for stability and ensure no components overheat. Review the manual for any final adjustments or settings. Once satisfied, store the manual for future reference and troubleshooting. Always follow safety guidelines to prevent accidents or system damage. Proper installation ensures reliable performance and security for your vehicle with the Viper 5305V system.
